Pneumatic Slide Table Cylinder – ±0.01mm Precision Compact Integrated High Rigidity Durable for Automation

Airtac offers a wide range of pneumatic cylinders, and some of the most popular types includes

1. Standard Cylinders 2. Compact Cylinders 3. Guided Cylinders 4. Rotary Actuators 5.Double-Acting Cylinders 6. Single-Acting Cylinders 7. Slide Cylinders 8. Swing Cylinders

Core Advantages

High Load Capacity: Designed to handle heavy loads without compromising on performance, making them ideal for high-demand applications.
Precision and Smooth Operation: Provide accurate, smooth movement with minimal friction, ensuring consistent performance and precision control.
Built-in Guide Rail: The integrated guide rail offers enhanced stability and precision, allowing the piston to move in a straight line, minimizing wear and tear.
Compact Design: Despite their high load capacity, these cylinders feature a space-saving design, ideal for applications where space is limited but high performance is required.
High Durability: Airtac linear slide cylinders are built with high-quality materials, ensuring they can operate efficiently even under harsh conditions, reducing the need for frequent maintenance.
Adjustable Stroke Length: These cylinders offer customizable stroke lengths, giving you flexibility in your automation systems

Categories: Airtac, Pneumatic Components, Pneumatic Cylinders, SMC

Description
Technical Parameters

The Industrial pneumatic cylinder is a high-performance, versatile pneumatic actuator designed for reliable linear motion in automated systems. Engineered with durable construction, compact integrated design, and low noise operation, it delivers stable thrust, fast response, and low maintenance to reduce downtime. Featuring heavy-duty load capacity, corrosion resistance, and easy installation with standard mounting slots, this universal air cylinder adapts to diverse working conditions, including high-speed cycling, precision positioning, and harsh industrial environments.

A wide range of pneumatic cylinders for different industrial applications, each designed to meet specific needs. Here are the main types of Airtac cylinders and their features:

1. Standard Cylinders (ISO Cylinders)

2.Table Slide Cylinder

3. Compact Cylinders

4. Double-Acting Cylinders

5. Single-Acting Cylinders

6. Guided Air Cylinders

7. Rotary Cylinders

8. Magnetic Cylinders

9. Tie Rod Cylinders

10. Air-Driven Cylinders

11. Push-Pull Air Cylinders

Core Advantages

✅ Unmatched Precision & Repeatability: ±0.01mm positioning accuracy with linear/cross roller guide, eliminates piston rod deflection and rotation—critical for medical device manufacturing

✅ Space-Saving Integration: Cylinder + guide rail all-in-one design reduces external support structures by 40%, fits tight automation cells

✅ Heavy Load & Torsion Resistance: Dual-piston rod or reinforced guide design delivers superior bending/torsion resistance, supports up to 50% higher side loads than standard cylinders

✅ Smooth, Quiet Operation: Built-in hydraulic/rubber buffer system minimizes impact noise to ≤65dB, enhances production line comfort

✅ Tool-Free Maintenance: Modular construction with pre-drilled mounting holes, magnetic switch slots, and floating joints for 3-minute installation/swap

✅ Extreme Environment Ready: Options for high-temperature (180°C), explosion-proof, and cleanroom compatibility—covers 95% of industrial applications

Application:

CNC Machining: Precise control for smooth cutting, drilling, and shaping of materials.
Robotic Arms: Enable high-speed pick-and-place operations with accuracy.
Automated Assembly Lines: Pneumatic grippers handle components quickly, improving throughput and quality control.
Packaging & Palletizing: Automates packaging, sorting, and palletizing processes for faster production.
Material Handling: Pneumatic systems are used for efficient transportation, handling, and sorting of materials.
Lithium Battery Manufacturing: Pneumatic cylinders precisely handle delicate components in battery assembly, ensure consistent electrolyte injection, and control packaging and sealing processes

How Pneumatic Cylinders Improve Automation Efficiency and Precision in Manufacturing?
The Advantages of Pneumatic Components in Automation Production Lines
Pneumatic cylinders and components are essential in modern automation systems, offering precision, energy efficiency, and reliable performance. Ideal for applications that require speed, accuracy, and durability, these systems are key in industries like robotics, CNC machining, automated assembly, and material handling.
Key Advantages of Pneumatic Cylinders in Automation
1. Precision & Accuracy
Pneumatic cylinders provide high-precision linear motion, critical for applications where even small deviations can impact production quality, such as CNC machining, robotic assembly, and pick-and-place operations.
- Accuracy up to ±0.01mm
- Repeatable movements for consistent results
- Reduces errors and improves quality control
2. Energy Efficiency
Pneumatic systems consume less energy while delivering greater force, thanks to their low-friction design. This efficiency reduces energy costs and enhances sustainability.
- Energy-efficient: Reduced power usage, same output
- Ideal for high-volume production and long hours
- Helps cut down operational costs
3. Reliability & Low Maintenance
Pneumatic components are durable, requiring minimal maintenance and offering long lifespans. This reliability reduces downtime and ensures smooth continuous production.
- Long lifespan and low maintenance
- Operates well in harsh environments
- Reduced downtime and easy upkeep
4. Compact Design
Pneumatic components are compact and lightweight, fitting into tight spaces without sacrificing performance. They are perfect for space-constrained environments like robotic arms and CNC machines.
- Space-saving design for efficient setups
- Easy integration into high-density production lines
- Flexible installation across various environments
5. Enhanced Safety
Pneumatic systems are inherently safe since they don’t rely on electricity. They are ideal for hazardous environments where flammable gases or chemicals are present.
- Explosion-proof and safe to use
- Perfect for flammable or hazardous environments
- Reduced risk of accidents compared to electric systems

Cylinder Type	Mini cylinder, guide frame clinder, Pen size cylinder, Thin Cylinder, Compact cylinder, Threaded cylinder, Twin-rod cylinder, Tri-rod cylinder, Slide table cylinder, Rotary table cylinder, Finger cylinder，Pen Cylinder
Bore Size (mm)	6, 8, 12, 16, 20, 25
Action Type	Double-acting
Working Fluid	Air
Operating Pressure Range	– Bore 6: 0.2~0.7 MPa (29~100 psi, 2.0~7.0 bar)
Proof Pressure	1.2 MPa
Stroke Tolerance	– Stroke ≤ 100 mm: +1.0 / 0 mm – Stroke > 100 mm: +1.5 / 0 mm
Cushion Type	Fixed cushion at both ends, or oil shock absorber cushioning
Compatible Sensors	CMSH, DMSH, EMSH ①
Port Thread Size	Bores 6, 8, 12, 16: M5×0.8
